How to solve the common faults of semi-electric stackers?

1. The height problem of the distribution fork of the semi-electric stacker

The fork of the semi-electric stacker has two forms, namely fixed pallet type and movable fork type. The fork thickness of the movable fork is 70mm by default, and it can also be customized according to customer requirements to increase or decrease the thickness of the fork. The semi-electric stacker manufacturer believes that this fault is caused by a gasket at the connection between the root of the movable fork and the semi-electric stacker. We can adjust the unevenness of the gasket through screws to achieve the purpose of adjusting the level of the fork.

2. Oil leaks from semi-electric stackers

Semi-electric stacker manufacturers believe that most of the oil leaks are caused by oil pipes and cylinders or pumps The joint of the station is not tightly sealed. You can use a wrench to tighten the nut at the joint for a few more turns, but remember not to use too much force, otherwise it will cause trouble. Assuming that the nut has been tightened and the oil is still leaking, you need to disassemble the nut, replace its gasket or explosion-proof valve with the correct type or a new one, and re-tighten it. Generally, such shortcomings can be solved. When removing the nut, it is necessary to lower the fork to the lowest level, so that all the hydraulic oil in the oil circuit can be returned to the cylinder of the pump station to avoid a lot of leakage.

3. The distribution balance wheel of the semi-electric stacker is not level.

This situation is mainly because the stacker deviates from the normal load. Center of gravity, resulting in excessive pressure on one side. Semi-electric stacker manufacturers suggest that the back cover can be opened, the screws on the distribution balance wheel are unscrewed, and some spacers are placed on the axle column of the lower balance wheel, or the spacer on the higher balance wheel is appropriately reduced. in order to reach a distribution balance.

4. Disadvantages of the circuit system

Although the circuit structure of the semi-electric stacker is not complicated, it should be frequently awakened for simple maintenance . It is not advisable to use a semi-electric stacker in the following situations, for example: when the battery voltage of the stacker is insufficient, when the battery is being charged, and when the battery is not used for a long time and the battery is depleted. Therefore, the semi-electric stacker manufacturer recommends that it is necessary to charge the semi-electric stacker frequently.

The above are some solutions for common faults of semi-electric stackers given by semi-electric stacker manufacturers. If you want to know more questions, please contact us .
