How to choose an electronic scale pallet truck?

How to choose anelectronic scale pallet truck?

Electronic scale pallet trucks are often used in industrial fields, such as factories, construction sites, roads, warehouses, etc. In addition to 3 tons, there are also 1 ton and 2 ton ranges. , 2.5 tons of pallet truck scale product prices are not much different, mainly depends on the function and material. So how much does an electronic scale pallet truck cost? How to choose.

The purchase method of the electronic scale pallet truck:

1. The selection of the scale of the electronic pallet truck:

1. When the load cell is actually used , the weight of the scale body and the vibration, shock, eccentric load, etc. should be considered. Therefore, the principles of selecting the load cell range for different weighing systems are also different. As a general rule, it can be selected according to the following methods: fixed load (weighing platform, container, etc.) variable load (load to be weighed)

2. Static weighing system with multiple load cells: Fixed load (weighing platform, container, etc.) Variable load (load to be weighed) Load cell rated load * number of load cells * 60% . (The coefficient of 60% is added considering factors such as vibration, shock, eccentric load, etc. In the selection of the load cell range, the following items should also be noted. First of all, the capacity of the selected load cell should meet as much as possible The value in the standard product series of the manufacturer, otherwise, the non-standard products are not only expensive, but also difficult to replace after damage. Secondly, in the same weighing system, it is not allowed to use electronic floor scale sensors with different rated loads. Otherwise, The system will not work properly. Furthermore, the so-called variable load refers to the actual load applied to the load cell. ), then its influence should be considered.

2. Selection of the structure and type of the electronic scale pallet truck

In the electronic weighing instrument, what kind of structure and type of load cell should be selected, mainly Look at the structure of the electronic weighing instrument and the environmental conditions used. If you want to order an electronic truck scale, you should generally use a bridge type load cell. Compared with the cantilever beam type load cell, the bridge type load cell is more convenient to install and debug, and the scale Because of the advantages of fast stationary speed, electronic truck scales often use bridge load cells. In addition, if it is used in a high temperature environment, a high temperature load cell or a load cell with a cooling water pipe should be selected; if used in alpine regions , a load cell with a heating device should be used.
